Description
| Technical Specifications | |
|---|---|
| Input power | 1,800 W |
| No-load speed | 3,500 rpm |
| Saw blade diameter | 305 mm (12″) |
| Bevel angle range | 0° – 45° (L / R) |
| Cutting capacity (0° / 90°) | 65 × 190 mm |
| Cutting capacity (45° / 90°) | 65 × 140 mm |
| Cutting capacity (0° / 45°) | 45 × 195 mm |
| Cutting capacity (45° / 45°) | 45 × 135 mm |
| Voltage | 220–240 V, 50/60 Hz |
| Weight | 16.3 kg |
| Construction & Design |
|---|
| Double bell structure for enhanced stability |
| Wide die-cast base for improved support during cutting |
